3kw MPPT Solar Inverter Three Phase Mppt Hybrid Inverter Low Frequency

Certification : CE, ISO9001

Model NO. : HT-SDP3KW

Phase : Three

Output Power : 3000W

Brand : Htonetech

Type : DC/AC Inverters

Power Source : Solar Power

Nature of Wave String : Square Wave Inverter

Overload Ability : 150%,10s

Display : LCD+LED

Electrical Insulation Properties : 2000VAC,1 Minute

Degree of Protection : IP20 (Indoor)

Working Altitude ( M) : ≤3000m

Communication Interface : RS485 (Optional)

Dynamic Response Time : 5%, S50ms

Inverter Efficiency : >90%

Power Factor (PF) : 0.99

Output Frequency : 50Hz +0.05 (Can Be Set 60Hz)

Wavefor Distortion Rate (Thd) : Linear Loads2%

Waveform : Pure Sine Wave

Transport Package : Wooden Box

Specification : 482x605x267mm

Trademark : htonetech

Origin : China

Supply Ability : 50000pieces/Year

Shipping Cost : To be negotiated| Freight Cost Calculator

After-sales Service : Yes

Warranty : 3year

Nature of Source Flow : Active Inverter

Contact Now

off Grid Inverter 3kw DC AC Solar System Low Frequency Solars off Grid Inverter Three Phase

Product Description

3kw MPPT Solar Inverter Three Phase Mppt Hybrid Inverter Low Frequency

Model	HT-SDP5KW	HT-SDP3KW
lsolation mode	Low Frequency Transformer
Dc Input
Rated voltage (Vdc)	48Vdc
Rated current (A)	104A	62.5A
Input voltage range (Vdc)	43-100V
AC Output
Rated power (KW)	5KW	3KW
Rated voltage	220V+3%
Number of phases	Single phase
Rated current (A)	23A	13.7A
Output frequency	50Hz +0.05 (Can be set 60Hz)
waveform	Pure sine wave
Wavefor distortion rate (THD)	Linear loads2%
Dynamic Response time	5%, s50ms
Power Factor (PF)	0.99
Inverter Efficiency	>90%
Electrical insulation properties	2000Vac,1 Minute
Protection Function
Overload Ability	150%,10s
Protection	input reverse polanity. under voltage, overvoltage, output over-current, short circuit, overheating etc.
Display	LCD+LED
Communication interface	RS485 (optional) machine
Method of working	Working continuously
Cooling method	intelligent fan-cooled
Short-circuit protection	No automatic recovery. need to restart the machine
Working Environment 8 Mechanical dimension
Degree of protection	IP20 (indoor)
Working Altitude ( m)	≤3000m
Working temperature (C)	-20~+50C
Relative humidity (C)	0-90%. No condensation
Noise (1 meter)	≤55dB
Unit size: (W x D X H)	482x605x267mm	482x605x267mm
Rererence weight (Kg)	65Kg	52kg
Our company can adjust parameter configuration according to user's requirement.

FAQ

1. Q: Are you a factory or a trading company?
A :We are a professional Solar Panels Manufacturer in China

2.How can we guarantee the products quality?
A :Always provide the esteemed buyer a pre-production sample before mass production; Always testing every product before despatching the shipments;

3.What products we can supply you?
A :Solar panels,inverter,controller,cable,support frame and other solar power systems

4. Q: Can the products pricing be cheaper?
A :Of course, you will be offered a a very good discount with large quantities.

5.. Q: Can print our company's logo on the pv panels?
A :Yes! And we accept the OEM&ODM orders.
